CG-Heater with Threaded Cartridge Heaters
| Material | SUS304 SUS321 INCOLOY-840 SUS316l | ||
| Diameter | 1 mm~50mm | ||
| Max operating temp | 900ºC | ||
| voltage | 12V-480V or as customer's demand | ||
| Heat intensity | Not exceeding40Wcm2 (advisable) | ||
| Insulation Material | Seawater purification magnesium oxide rod, high temperature magnesium oxide powder | ||
| Resistance wire element | Cr20Ni80 | ||
| Lead Connection Option | Crimped or Swaged leads | ||
| Lead and type of connection leads | 12" Fiberglass Standard(Wire Options: Silicone /PFA/High Temperature Fiberglass/SS Braided | ||
| Cold areas | 5-25mm | ||
| Internal thermocouple | type J,K or E | ||
| Thermocouple Location | Disc End, Sheath, Center of Heater; | ||
Application:
| Plastic extruders/Plastic molding/Hot runner molds/Shoe machinery/Hot stamping/Food processing/Medical equipment/Heating gases and liquid/Packaging equipment/Glue guns/Molds and dies |
Fast heating rate, long service life, no leakage of work
SUS304 or SUS321 seamless stainless steel tube
99% high-purity magnesium oxide rod, Cr20Ni80
nickel fierce material lead-out electrode
External UL certification brand outer fiber copper core wire
Purified seawater magnesium rod and magnesium powder
